Davit Systems

Permanent Base Davit Fall Protection System

The same trusted Pelsue davit mast — permanently anchored wherever your operation demands it. Floor, wall, corner, or cylinder core mounts in coated steel, stainless, or galvanized. Man-rated to 310 lbs., built from structural aluminum, set up in minutes. Hoists sold separately.
OSHA Compliant. ANSI Certified. Made in USA.

310 lb Capacity
310 lb Capacity
~5 Setup
~5 Setup
60" + ext. Post Height
60" + ext. Post Height
Structural Aluminum
Structural Aluminum
Three Models
DK1824
18"/24" offset arm · 45 lbs. · base sold separately
DK3036
30"/36" offset arm · 48 lbs. · base sold separately
DK4248
42"/48" offset arm · 51 lbs. · base sold separately
Connect with a Safety Partner
permanent-base-davit-fall-protection
Fall Protection & Rescue

One System. Every Application.

The Permanent Base Davit works for both fall protection and rescue & retrieval in the same configuration. Permanently anchored at your most-used entry points, it eliminates the setup time of portable systems entirely — the arm is ready the moment your crew arrives. Choose your offset arm, sleeve mount, and hoist to build exactly the system your operation requires.

Works for fall protection and rescue & retrieval in one configuration
Works for fall protection and rescue & retrieval in one configuration
Three offset arm options — 18"/24", 30"/36", 42"/48" reach
Three offset arm options — 18"/24", 30"/36", 42"/48" reach
Additional mounting location for running two systems simultaneously
Additional mounting location for running two systems simultaneously
Man-rated to 310 lbs. — meets or exceeds OSHA & ANSI standards
Man-rated to 310 lbs. — meets or exceeds OSHA & ANSI standards
Technical Details

Model Comparison

Specification
DK1824
DK3036
DK4248
Kit Contents
Center post (CP60), elbow (EM01), 18"/24" offset arm (BA24)
Center post (CP60), elbow (EM01), 30"/36" offset arm (BA36)
Center post (CP60), elbow (EM01), 42"/48" offset arm (BA48)
Offset Arm SKU
BA24
BA36
BA48
Offset Reach
18" or 24"
30" or 36"
42" or 48"
Arm Weight
7 lbs
10 lbs
12 lbs
Kit Weight
45 lbs
48 lbs
51 lbs
Center Post (CP60)
Aluminum, 60" H with hoist mounting bracket · 26 lbs.
Aluminum, 60" H with hoist mounting bracket · 26 lbs.
Aluminum, 60" H with hoist mounting bracket · 26 lbs.
Elbow (EM01)
Fabricated aluminum, reversible for different offset lengths · 13 lbs.
Fabricated aluminum, reversible for different offset lengths · 13 lbs.
Fabricated aluminum, reversible for different offset lengths · 13 lbs.
Capacity
310 lb man-rated
310 lb man-rated
310 lb man-rated

Full Specifications

Complete Arm Kits
  • DK1824 — Center post, elbow, 18"/24" arm (BA24) · 45 lbs. · base & hoist sold separately
  • DK3036 — Center post, elbow, 30"/36" arm (BA36) · 48 lbs. · base & hoist sold separately
  • DK4248 — Center post, elbow, 42"/48" arm (BA48) · 51 lbs. · base & hoist sold separately
Individual Parts
  • CP60 — Center post with hoist mounting bracket, aluminum, 60" H · 26 lbs.
  • EM01 — Elbow, fabricated aluminum, reversible · 13 lbs.
  • BA24 — Offset arm, 18"/24" reach, with pulley & U-bracket · 7 lbs.
  • BA36 — Offset arm, 30"/36" reach, with pulley & U-bracket · 10 lbs.
  • BA48 — Offset arm, 42"/48" reach, with pulley & U-bracket · 12 lbs.
Center Post Extensions
  • CPX-15 — 15" extension, powder coated steel · 22 lbs.
  • CPX-24 — 24" extension, powder coated steel · 25 lbs.
  • CPX-36 — 36" extension, powder coated steel · 31 lbs.
System Components

Build Your Configuration

The Portable Davit System is fully modular — select the arm kit, base, and extensions that fit your operation. All parts are available individually for replacement or custom builds.

EM01

EM01 - Davit Elbow

Fabricated aluminum, reversible for different offset lengths. 13 lbs.

BA24

BA24 - Offset Arm 18"/24"

Aluminum with pulley & U-bracket. 18"/24" offset reach. 7 lbs.

BA24

BA36 - Offset Arm 30"/36"

Aluminum with pulley & U-bracket. 30"/36" offset reach. 10 lbs.

BA24

BA48 - Offset Arm 42”/48”

Aluminum with pulley & U-bracket. 42”/48” offset reach. 10 lbs.

CP60

CP60 - Davit Center Post

Aluminum, 60"H with hoist mounting bracket. 26 lbs.

CPX-24

CPX-15 - Center Post Extensions

15" powder coated steel extensions for added height.

CPX-24

CPX-24 - Center Post Extensions

24" powder coated steel extensions for added height.

CPX-24

CPX-36 - Center Post Extensions

36" powder coated steel extensions for added height.

BGDK

BGDK - Davit Carry Bag

Carry bag for DK Series kits. Protects components during transport and storage.

Compatible Equipment

Hoists, SRLs, & Brackets

The Permannent Davit System is compatible with Pelsue’s full line of hoists, SRLs, and brackets — sold separately to complete your fall protection or rescue configuration.

PersonnelHoist2

Personnel Hoists

View Product

Personnel Hoists
EquipmentHoist-1024x622

Equipment Hoists

View Product

Equipment Hoists
quick_rescue_hoist

Quick Rescue Hoists

View Product

Quick Rescue Hoists
standard-self-retracting-lifelines

Standard Self-Retracting Lifelines

View Product

Standard Self-Retracting Lifelines
3-way-self-retracting-lifelines

3-Way Self-Retracting Lifelines

View Product

3-Way Self-Retracting Lifelines
501178-001-_MB-FSB_

MB-FSB Bracket

Bracket to attach all SRLs to MB-PF1 quick-connect bracket

Mount Configurations

Permanent Mount Sleeves & Bases

18+ sleeve and base options in coated steel, stainless steel, and galvanized — floor, wall, corner, cylinder core, and portable wall mounts for every job site condition.

Floor & Flush Mounts

Model
Description
DSP-F1
Floor mount — anchors to floors, truck beds, catwalks · 24 lbs. · Coated
DSS-F1
Floor mount — stainless steel · 24 lbs.
DSP-F2
Center floor mount — floors, truck beds, catwalks · 24 lbs. · Coated
DSS-F2
Center floor mount — stainless steel · 24 lbs.
DSP-C1
Flush floor — fresh pour concrete, low trip hazard · 21 lbs. ·
DSS-C1
Flush floor — fresh pour concrete, stainless · 21 lbs.
DSP-F3
Flush floor — existing concrete, drilled & bolted · 23 lbs. · Coated
DSS-F3
Flush floor — existing concrete, stainless · 23 lbs.

Wall, Corner & Cylinder

Model
Description
DSP-W1
Wall mount — truck bumpers, tank walls, catwalks, meter pits · 22 lbs. · Coated
DSS-W1
Wall mount — stainless steel · 22 lbs.
DSP-A1
Inside 90° corner — bolted to reinforced bumpers or walls · 26 lbs. · Coated
DSP-A2
Outside 90° corner — bolted to reinforced bumpers or walls · 26 lbs. · Coated
DSP-C2
Cylinder core — drilled into existing or poured into fresh concrete · 9 lbs. · Coated
DSS-C2
Cylinder core — stainless steel · 9 lbs.
DSP-F3
Flush floor — existing concrete, drilled & bolted · 23 lbs. · Coated
DSS-F3
Flush floor — existing concrete, stainless · 23 lbs.

Portable Wall Bases & Sleeve Caps

Model
Description
DSR-S03
Portable wall mount — clamps walls up to 3" thick (8 bolts) · 58 lbs. · Zinc
DSR-A08
Clamping portable wall mount — 3" to 8" thick walls · 35 lbs. · Coated
DSR-ADJ
Adjustable wall mount — clamps 1" to 23.25" thick walls · 55 lbs. · Coated
DSC-S2
Sleeve cap — zinc plated steel, rubber seal, seals sleeve when not in use · 1 lb. · Zinc
DSC-S1
Sleeve cap — stainless steel, rubber seal · 1 lb.
DSC-P1
Sleeve cap — ABS plastic, rubber seal · 0.24 lbs.
DSP-F3
Flush floor — existing concrete, drilled & bolted · 23 lbs. · Coated
DSS-F3
Flush floor — existing concrete, stainless · 23 lbs.
